| Place of Origin: | China |
| Certification: | CE |
| Model Number: | AZ01 |
Appearance and opening size:
|
Model |
AZ01(SSR-D/A) 10-80A |
|
Input voltage
|
3-32VDC |
|
Input current |
6-35MA |
|
Pick-up voltage |
3VDC |
|
Release voltage |
1VDC |
|
Reverse voltage |
32VDC |
|
Output voltage |
22:24-240VAC, 38:40-440VAC |
|
Output current |
10A,15A,20A,25A,30A,40A, 60A, 80A |
|
Instantaneous voltage |
22: 600VAC, 38:900VAC |
|
Generalized hypotension |
1.6VDC |
|
Switching time |
10MS |
|
leakage current |
10MA |
|
Insulation strength |
2500VAC |
|
Insulation resistance |
500MΩ,500VDC |
|
Ambient temperature |
-30℃ to 80℃ |
|
Display |
LED |
|
Attention |
When the output current is greater than 10A, a radiator is required, and when the output current is greater than 80A, a fan is required. |
